- Size: 0.2
- Place of Origin: Ningbo
- Brand Name: PULI
- Model Number: PL-V9500
- Weight: 40.000 kg
Specifications
Rated Line Pull: 9500LB(4310kg) single-line
Motor: 5.5hp/4kw 12V, Series Wound motor
Gear Train: 3-stage planetary
Gear Reduction Ratio: 265:1
Clutch: Up and down 90°
Cable φ3/8”×92” (φ9.5mm×27m)
Drum Size: φ2.51”×8.82”(φ64mm×224mm)
Overall Dimensions: (L×W×H)21.5”×6.3”×8.7”(546×160×222mm)
Gross Weight: 89lbs(40kg)
Duty Cycle: Intermittently
Fairlead: 4-way roller fairlead
Package: 1pc/box, 600x343x255mm
Mounting Bolt Pattern: 10”x4.5”(254mm x 114.3mm )
Remote Control: Included
Note clutch style, solenoid, brake system can be chosen, different cost
